Place of Origin: | China |
Brand Name: | OEM |
Model Number: | T96 PLUS |
Minimum Order Quantity: | 1PCS |
---|
OEM &ODM Order are warm welcomed !
Note: We would send correct US, EU, UK, AU Power charger adapter depends on your country!
Function:
Full Specification:
Item |
Description |
|
|
Dimension |
112*112*19mm |
System Config. |
CPU |
Amlogic S912 Octa-Core ARM Cortex-A53 64-bit @2GHz |
GPU |
Mali-T820MP3 GPU @ 750MHz, |
|
RAM |
DDR3 3GB |
|
ROM |
Onboard eMMC Flash 16GB |
|
Bluetooth |
BT4.1 |
|
Antenna |
Built-in antenna for Wi-Fi |
|
Expand Memory |
Micro SD Card ( support 4 - 64GB) |
|
Communication |
Ethernet |
1000Mbps LAN |
Wi-Fi |
IEEE 802.11 b/g/n/ac,2.4G/5.8G |
|
Video/Picture Decoding |
* AMLogic video Engine(AVE)with dedicated hardware decoders and encoders * Supports multiple "secured"video decoding sessions and simultaneous decoding and encoding * Video/Picture Decoding -VP9 Profile-2 up to 4K*2K 60fps -H.265 HEVC MP-10@L5.1 up to 4K*2K@60fps -H.264 AVC HP@L5.1 up to 4K*2K@30fps -H.264 MVC up to 1080P@60fps -MPEG-4 ASP@L5 up to 1080P@60fps(ISO-14496) -WMV/VC-1 SP/MP/AP up to 1080P@60fps -AVS-P16(AVS+) /AVS-P2 JiZhun Profile up to 1080P@60fps -MPEG2 MP/HL up to 1080P@60fps -MPEG1 MP/HL up to 1080P@60fps -RealVideo 8/9/10 up to 1080P@60fps * Low latency 1080P H.264 60fps encoder * HDR10 and HLG HDR Video Processing * Supports *.mkv,*.mpg,*.wmv,*.mpeg,*.dat,*.avi,*.mov,*.iso,*.mp4,*.rm and *.jpg file formats * Video/Picture Encoding -Independent JPEG and H.264 encoder with configurable performance/bit-rate -JPEG image encoding -H.264 video encoding up to 1080P@60fps with low latency |
|
Audio format |
Low power MediaCPU with DSP audio processing Supports MP3,AAC,WMA,RM,FLAC,Ogg and programmable with 7.1/5.1 down-mixing Built-in stereo audio DAC Built-in SPDIF/IEC958 and PCM serial digital audio input/output Supports concurrent dual audio stereo channel output with combination of analog+PCMo or I2S+PCM |
|
Indicator |
Power LED |
Circule LED Breathing Lamp |
Button & Ports |
Button |
Touch Power Button |
Operating system updates(via USB port/TF Card Slot) |
||
USB2.0 |
2* USB:1* USB Host Port ,1*USB Device |
|
DC-in |
1*DC in Jack |
|
HD |
1*4K*2K UHD Output, HD 2.0a |
|
AV |
1*AV Port |
|
SPDIF |
1*Digital Audio output |
|
RJ45 |
1*RJ45 |
|
SD Card Slot |
1* Micro SD Card |
|
Power management |
Adapter |
5V 2A |
Software Config. |
OS |
Android 6.0 Marshmallow |
Language |
Multi -language |
|
Features |
Miracast/DLNA |
Support |
Work Environment |
5°C--35°C,30%--90% Humidity |
|
Storage Environment |
-20°C--60°C,10%--90% Humidity |
Accessories:
Product Detail Photos:
